Variable Fiber Optic VOA In-Line Attenuator, SM/MM, 0~60dB

Variable Fiber Optic VOA In-Line Attenuator, SM/MM, 0~60dB

Customized Variable Fiber Optic VOA In-Line Attenuator, SM/MM, 0~60dB

Variable Fiber Optical Attenuators

As optical passive devices, FXK attenuators are mainly used in fiber optic to debug optical power performance & optical instrument calibration correction & fiber signal attenuation to ensure the optical power in a stable and desired level in the link without any changes on its original transmission wave.

Specification:

Fiber Connector	SC	Ferrule Type	Zirconia Ceramic
Connector Gender	Fixed Male to Female	Transfer Mode	Singlemode
Operating Wavelength(nm)	1260~1620(SM)	Humidity	95%RH
Attenuation Accuracy	±0.5dB	Return Loss	UPC≥50dB; APC≥60dB
Operating Temperature Range	-40~85°C	Storage Temperature Range	-40~85°C
Polarization Dependent Loss	≤0.2dB	Minimize Insertion Loss	<2.5dB
Attenuation	1dB 3dB 5dB 6dB 7dB 10dB 15dB 20dB 25dB
