Ftth SC/UPC Single Mode Duplex Optical Fiber Optic Cable Quick Fast Connector Adapter
Single Mode OEM ODM Fiber Optic Adapter Quick Fast Sc Duplex Connector
1.Description
Fiber Optic Adapter is a fiber optic connector for connecting components, fiber optic communication equipment, instruments and so on, the performance is stable and reliable.
The optical fiber is connected by an adapter through an internal aperture sleeve. We provide all kinds of high performance adapter in order to ensure maximum connectivity between the optical fiber jumper.
In order to fixed in various panels, we have designed a variety of fine flange mounting.
2. Specification
Type | SC/FC/ST/LC/MU/MTRJ/MPO |
Insertion Loss(dB) | SM≤0.2dB, MM≤0.3dB |
Repeatability(dB) | ≤0.1dB |
Mechanism Durability(500 cycles, dB) | ≤0.2dB |
Temperature Range | -40°C-+85°C |
Material of sleeve | Zirconia or Bronze |
Item | Test Name | Additional Insertion Loss | Additional Return Loss |
1 | Mechanical durability | <0.2dB | <5dB |
2 | Repeatability | <0.2dB | <5dB |
3 | Lock strength | <0.2dB | <5dB |
4 | Low strength | <0.2dB | <5dB |
5 | High temperature | <0.2dB | <5dB |
6 | Steaming | <0.2dB | <5dB |
7 | Temperature cycle | <0.2dB | <5dB |
8 | Vibration | <0.2dB | <5dB |
9 | Drop | <0.2dB | <5dB |
